Jazzy EVO 614 HD (FDA Class II Medical Device)

SKU JEVO614HD-BLK
Color: Black (Matte)
"White Glove In-home Delivery and Installation"
( 1 year FREE service warranty included when in San Diego County)
Description

The Jazzy EVO 614HD provides the freedom to navigate small spaces indoors along with the ability to handle terrain, so thresholds, transitions, and grassy fields feel smoother than ever before. Jazzy EVO 614HD has tall 13.75-inch drive wheels, the centerpiece for Pride’s beloved Mid-Wheel 6 platform. Active-Trac ATX Suspension adapts to the terrain, so grassy fields and paths feel smoother than they ever have before.

Jazzy EVO 614HD has tall 13.75-inch drive wheels, the centerpiece for Pride’s beloved Mid-Wheel 6 platform. Active-Trac ATX Suspension adapts to the terrain, so grassy fields and paths feel smoother than they ever have before.

Features
  • 450 lbs. weight capacity
  • Up to 4.88 mph
  • 22” turning radius
  • Up to 13 miles per charge at 450lbs, up to 21.5 miles per charge at 200lbs.
  • New! Depth-adjustable, limited recline memory foam high-back seat with headrest and single heavy-duty seat post allows the user to swivel
  • New! 13.75” perforated drive tires
  • New! 60-amp Dynamic LiNX Adjustable joystick speed dial enables you to adjust your speed comfort level
  • New! Removable matte finish color through shrouds and 6-colors
  • Flip-up, height adjustable foot platform
  • Full independent front and rear Active-Trac® ATX Suspension for enhanced performance over more varied terrain
  • In-line joystick mount
  • Convenient access to the controller and batteries while the user remains seated
  • HCPCS Code: Group 2: Heavy-Duty (K0824/K0825)
Specification

Size

  • Overall Dimension: 40.5" l x 25.75" w (103x65cm)
  • Seat Dimension:
    • 18" x 18"- 20 (46x46-51cm)
    • 20" x 18"- 20 (51x46-51cm)
    • 22" x 20"- 22 (56x51-56cm)
  • Seat-to-Floor Range: 22-24” (56-61cm)
  • Turning Radius: 22" (56cm)
  • Wheel Size
    • Front Casters: 6" (15cm)
    • Drive Wheel perforated: 13.75” (35cm)
    • Rear Casters: 6" (15cm)

Details

  • Maximum Speed: Up to 4.88 mph
  • Drivetrain: Two motor, in-line, HD motors
  • Braking System: Regenerative and electro-mechanical
  • Suspension Type: Full independent front and rear Active-Trac® (ATX) Suspension
  • Standard Seat: High-back, memory foam; Black vinyl
  • Standard Electronics: 60A, Dynamic Linx
  • Battery Requirements(s): (2) NF-22
  • Battery Charger: 5-amp, off-board
  • Per Charge Range: 13 miles at 450 lbs., 21.5 miles at 200 lbs.
  • Weight:
    • Seat: 57.8 lbs.
    • Battery: 36 lbs.
    • Heaviest Piece: 125.7 lbs. (base)
  • Total Weight with batteries and seat: 255.5 lbs.
  • Warranty:
    • Frame: 5-year limited
    • Drivetrain: 13-month limited
    • Electronics: 13-month limited
    • Batteries: 13-month limited
