TRANSITIONS® Modular Entry Ramp

TRANSITIONS® Modular Entry Ramp

by EZ-Access
SKU
Description

The TRANSITIONS Modular Entry Ramp is perfect for doorways to create a smooth, sturdy, and seam-free surface for wheelchair, scooter, walker, and cane users. It is made with high-strength aluminum that will never rust or corrode and has an extruded slip-resistant surface for superior traction. Ideal for doorways, sliding glass doors, and raised landings. It is lightweight and easily transported from one place to the next for added convenience. Sizes are available to accommodate thresholds up to 6.25" high. Browse through the tabs below to learn more.

Features
  • Lightweight and high strength
  • Available in 1", 1.5", 2", 3", 4", 5" and 6" rises
  • Easy installation, modification, and transportation
  • Slip Resistant surface
  • Adjustable Flap
  • Modular Design
  • Constructed of extruded, anodized aluminum that will not rust or corrode
  • Durable non-skid driving surface
Specification

Size

  • Overall Dimensions
    • Usable Size with Top:
      • TMER1: 6.67" x 34" x 1" (17x86x2cm)
      • TMER1.5: 9.19" x 34" x 1.5" (23x86x4cm)
      • TMER2: 11.67" x 34" x 2" (30x86x5cm)
      • TMER3: 6.64" x 34" x 3" (17x86x8cm)
      • TMER4: 21.64" x 34" x 4" (55x86x10cm)
      • TMER5: 26.64" x 34" x 5" (68x86x13cm)
      • TMER6: 31.64" x 34" x 6" (80x86x15cm)
    • Usable Size without Top:
      • TMER1: 4.82" x 34" x 1" (12x86x2cm)
      • TMER1.5: 7.32" x 34" x 1.5"(18x86x4cm)
      • TMER2: 9.8" x 34" x 2" (25x86x5cm)
      • TMER3: 14.77" x 34" x 3" (37x86x8cm)
      • TMER4: 19.77" x 34" x 4" (50x86x10cm)
      • TMER5: 24.77" x 34" x 5" (63x86x13cm)
      • TMER6: 29.77" x 34" x 6" (76x86x15cm)
  • Usable Height:
    • TMER1: 0.75" - 1.25" (2-3cm)
    • TMER1.5: 1.25" - 1.75" (3-4cm)
    • TMER2: 1.75" - 2.25" (4-6cm)
    • TMER3: 2.75" - 3.25" (7-8cm)
    • TMER4: 3.75" - 4.25" (9-11cm)
    • TMER5: 4.75" - 5.25" (12-13cm)
    • TMER6: 5.75" - 6.25" (15-16cm)

Material

Aluminium

Details

  • Made Of Aluminum: yes
  • Slip-Resistant Surface: yes
  • For Residential Use: yes
  • For Wheelchairs & Scooters: yes
  • Weight
    • TMER1: 3 lbs
    • TMER1.5: 5 lbs
    • TMER2: 5.5 lbs
    • TMER3: 8 lbs
    • TMER4: 11 lbs
    • TMER5: 15 lbs
    • TMER6: 20 lbs
  • Weight Capacity: 700 lbs
  • Warranty: Lifetime

Measuring Guide

ramp measuring guide
